Idea 050 - Tessellating Illuminated Origami Wall Sculpture
This post is part of the 100 project ideas project. #The100DayProject. I am looking for feedback. Comment below or DM me via social media Instagram, Twitter.
👉 Done! See this instagram post
One Line Pitch
Origami Sacred Geometry + Individually addressable RGB LEDs + Wall Sculpture + interactive
Description
Tiling tessellating star shaped modular Origami in a repeating pattern. Similar to Kinga Kubowicz - Moduuli 2 or Origami Mosaics by Kota Hiratsuka
Each cell will have its own Individually addressable RGB LEDs similar to my Digital Stained Glass Windows project.
Though the sculpture scatters a few human detection sensors like Passive infrared (PIR) sensor or Nondispersive Infrared (NDIR) Sensor. This allows me to determine if there is a person looking at the sculpture or where in the sculpture they are located. This information can be used in the LED animations.
Mount the whole sculpture onto a plywood board that can be hung on the wall with a French cleat.
The tiling Origami shapes would be created with plastic Vellum Paper. Semi transparent and a good diffuser for LED light as well as foldable for Origami shapes. It’s also plastic so it should hold its shape well and could be cleaned with a damp cloth. It is more expensive then normal paper at $12 for 50x sheets but the advantages over normal paper should be worth it.
Use a ESP32 for the brains, then it can connect to the internet or home assistant to provide more information.
Prior art
- Serenity: An origami wall sculpture - Includes LEDs but not every title has its own LED, and it uses pyramids instead of stars.
- Origami Sacred Geometry - Tiling, tessellating, module Origami in similar shapes.
- Kinga kubowicz’s Moduuli - The shape I am looking for. The paper already has the shape and uses staples to connect each section. A lot easier to manufacture than traditional Origami.
- Video on how to make piramide
Market
People who want interactive beautiful wall sculptures that display information as well as pretty colors.
Implementation
- Prototype 2
- Prototype 1 - Fail
- Animation of how to fold the segments
- Printable files of the segments
